YOUR RESTAURANT HOOD PACKAGE INCLUDES:

• Exhaust Fan (1pc) 28D 2000 CFM, 115V
• Supply Fan (1pc) SF7 Untempered 1600 CFM, .250 SP, 230V, 60HZ
• Mounting Curb Wall / Roof (2pcs)
• New 304 Stainless (IPS) Internal Perforated Supply Plenum
• Stainless Steel UL listed Grease Baffle Filters

RESTAURANT HOOD PACKAGE FEATURES

• 8 FT Hood System
• All hoods are constructed of 18 gauge steel
• All joints are welded liquid tight, without seams by an automatic wire fed mig welder
• Made in USA
• All hoods are UL710 Listed and built in accordance with NFPA 96, NSF specifications.

MAKEUP-AIR HOODS – OVERVIEW

Ventwell’s Short Cycle Make Up Air with IPS (Internal Perforated Supply) removes grease laden vapors from the air while replacing air without causing negative air pressure. This allows using a fresh air makeup air fan instead of a costly tempered air unit. IPS (Internal Perforated Supply Plenum) takes advantage of the Coanda Effect created inside the hood, further assisting with capture and containment. The design of makeup air hoods allows for the comfort of the employees working in the kitchen to maintain a comfortable temperature for working and does not have hot air blowing down on their head as they are cooking and preparing food.
